JQH-02 High Speed Lipgloss Filling Machine with 80 PCS/MIN Output and Rotary Capping System

Large Image : JQH-02 High Speed Lipgloss Filling Machine with 80 PCS/MIN Output and Rotary Capping System

Product Details:

Place of Origin:	China
Brand Name:	Gieni
Model Number:	JMF

Payment & Shipping Terms:

Minimum Order Quantity:	1SET
Price:	Negotiable
Packaging Details:	Film+Polywood Case
Delivery Time:	45 days
Payment Terms:	L/C,T/T
Supply Ability:	1set per 45 days

Contact Now

JQH-02 High Speed Lipgloss Filling Machine with 80 PCS/MIN Output and Rotary Capping System

Description

Application:	Mascara,Lipgloss	Machine Material:	SUS304
Dimension:	8105701906mm	Country Of Origin:	China
Warranty:	One Year	Output:	Max.output Is 22~28pcs/min By One Operator

JQH-02 High Speed Lipgloss Filling Machine | 80 PCS/MIN Servo Piston Filler | Rotary Capping System

Engineering Excellence in High-Speed Filling

The JQH-02 Automatic Lipgloss Filling and Capping Machine represents a paradigm shift in liquid packaging for medium-to-large scale cosmetics manufacturers. This system combines mechanical precision with electronic control to deliver craftsman-level care at industrial speeds.

Dual-Station Rotary Design for Maximum Efficiency

Unlike traditional linear fillers, the JQH-02 utilizes a Rotary Dial Indexing System with dual-station operation:

Station 1 (Filling): Bottles are filled with servo-driven precision while previously filled bottles undergo capping
Station 2 (Capping): Filled bottles move to capping while newly capped bottles move to ejection

This overlapping process eliminates idle time, enabling sustained operation at 80 pieces per minute without vibration or stress.

Precision Servo Piston Technology

The JQH-02 employs High-Precision Servo Pistons for superior performance with viscous products:

Positive Displacement: Physically pushes product out, ensuring consistent volume accuracy

Programmable Profiles: Adjustable piston speed prevents splashing and air entrapment

Durability: 316L stainless steel with ceramic valves handles abrasive and corrosive materials

Vacuum Drip Control System

Advanced Vacuum Drip Control ensures pristine bottle presentation:

Clean threads for smooth cap application
Prevents "angel hair" formation with high-viscosity liquids
Maintains brand integrity with factory-fresh appearance

Complete Automated Assembly

The JQH-02 functions as a complete assembly line with integrated features:

Automated Wiper Loading: Precisely places inner wipers for optimal consumer experience
Servo Capping: Applies specific, measurable torque to prevent cross-threading
Auto-Rejection: Integrated vision systems detect and remove non-conforming units

Versatile and Future-Proof Design

Engineered for rapid changeovers to adapt to evolving market demands:

Mascara with long-wear, fiber-rich formulas
Nail polish and solvent-based lacquers
Liquid lipstick with high-pigment, matte formulas

Technical Specifications

Parameter	Value	Operational Impact
Model	JQH-02	Industry-standard heavy-duty model
Speed	60 - 80 PCS/MIN	High-volume output for mass retail
Filling Range	1 - 20 ML	Handles samples to full-size SKUs
Filling Accuracy	±0.1 G	Reduces costly product giveaway
Filling Method	Servo Piston	Handles high-viscosity & particulates
Control System	PLC + HMI Touchscreen	Stores 50+ recipes for quick changeovers
Power Supply	3P 380V, 13KW, 40A	Stable industrial power for 24/7 operation
Air Pressure	0.5 - 0.8 MPa	Clean, dry air required
Material Contact	316L Stainless Steel / PTFE	Corrosion-resistant and easy to clean

Enhanced Operator Experience

Designed for ease of use and operational efficiency:

Intuitive HMI: Color touchscreen with graphical icons and one-touch recipe selection
Tool-less Changeover: Handles and pucks swap without specialized tools
Safety First: Full stainless steel guarding with safety interlocks

Comprehensive Partnership Support

We provide complete support throughout your machine lifecycle:

Factory Acceptance Testing (FAT): Test your actual bottles and formulas before shipment
Installation & Commissioning: Global engineering support for setup and staff training
Lifetime Support: Access to spare parts and 24/7 remote troubleshooting

Frequently Asked Questions

What types of bottles can the JQH-02 handle?

The JQH-02 is specifically designed for irregular-shaped bottles (octagons, squares, curves) that typically cause issues on standard conveyors. It uses custom pucks to stabilize any shape.

How accurate is the filling for expensive pigments?

Extremely accurate. Our servo piston system maintains a tolerance of ±0.1 grams, ensuring you don't lose money on overfilling expensive pigments or glitters.

Can this machine handle glitter or shimmer particles?

Yes. The 316L stainless steel pistons and valves are designed to handle abrasive materials like cosmetic glitter without wearing out quickly.

What is the lead time for the JQH-02?

Typically 45-60 days from deposit to shipment, including FAT (Factory Acceptance Testing).
