Cosmetic Filling Machine
Created with Pixso.

Cream 60ppm Dia 19mm Plastic Tube Filling Sealing Machine

Cream 60ppm Dia 19mm Plastic Tube Filling Sealing Machine

Brand Name: GIENI
Model Number: GFS
MOQ: 1 set
Price: Negotiable
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1
Detail Information
Place of Origin:
Shanghai
Certification:
according to customers
Type:
Tube Filling And Sealing Machine
Application:
Foundation Cream, Hand Cream, Concealer, Eyecream,,etc
Driven Type:
Servo Driven
Place Of Origin:
Shanghai
Certificate:
According To Customer
Outer Dimension:
1890*1083*2172mm(LXWXH)
Voltage:
AC380V,3P,50/60Hz
Capacity:
60 Ppm
Packaging Details:
plywood case
Supply Ability:
1
Highlight:

60ppm Tube Filling Sealing Machine

,

19mm Tube Filling Sealing Machine

,

200ml Tube Filling Sealing Machine

Product Description

Factory Price Automatic foundation cream Plastic Tube Filling Sealing Machine



Technical Parameter:



It is suitable for tubes with dia. of 19mm; 35mm; 50mm;

Filling volume can be: 5ml; 50ml; 200ml;

Production speed of this machine: 60ppm;

Air source needed: compressed air 6bar;

Air consumption: 5cmph (metal tube); 56cmph (heating type);

Water consumption: 200L/H (heating type);

Power consumption: 1.25kw (metal tube); 5.3kw (heating type);

Machine size: 1890*1083*2172mm

Eye Mark Detect

Cream 60ppm Dia 19mm Plastic Tube Filling Sealing Machine 0





Hot Air Blowing and Sealing Station

Cream 60ppm Dia 19mm Plastic Tube Filling Sealing Machine 1



Changing Parts for different tube diameter

Cream 60ppm Dia 19mm Plastic Tube Filling Sealing Machine 2





Filling Station, tube lift-up

Cream 60ppm Dia 19mm Plastic Tube Filling Sealing Machine 3





Touch Screen Control

Cream 60ppm Dia 19mm Plastic Tube Filling Sealing Machine 4





Tube Loading and detecting:

Cream 60ppm Dia 19mm Plastic Tube Filling Sealing Machine 5





Cream 60ppm Dia 19mm Plastic Tube Filling Sealing Machine 6Cream 60ppm Dia 19mm Plastic Tube Filling Sealing Machine 7
