3 Layers 50ml Lip Balm Stick Cosmetic Filling Machine With 4 Nozzles

3 Layers 50ml Lip Balm Stick Cosmetic Filling Machine With 4 Nozzles

    • 3 Layers 50ml Lip Balm Stick Cosmetic Filling Machine With 4 Nozzles
    • 3 Layers 50ml Lip Balm Stick Cosmetic Filling Machine With 4 Nozzles
    • 3 Layers 50ml Lip Balm Stick Cosmetic Filling Machine With 4 Nozzles
    • 3 Layers 50ml Lip Balm Stick Cosmetic Filling Machine With 4 Nozzles
  • 3 Layers 50ml Lip Balm Stick Cosmetic Filling Machine With 4 Nozzles

    Product Details:

    Place of Origin: SHANGHAI, CHINA
    Brand Name: GIENI
    Certification: CE
    Model Number: JYF-4

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: plywood case
    Delivery Time: 45
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 1
    Contact Now
    Detailed Product Description
    Product Name: Lip Balm Filling Equipment Balm Stick Cosmetic Filling Machine Filling Volume: 1-15ml;10-50ml;30-100ml
    Filling Type: Cold Filling And Hot Filling Output: 15-45pcs/min
    Material: Contact Material Part: SUS316L, Meet GMP Standard Nozzle Type: Driven By Servo, Can Lift Up And Down
    Filling Tank: 3 Layers, Outer Layer SUS304, Inner Layer SUS316L Service Provided: Online Support, Video Call Technical Support, Free Repair Parts, Onsite Installation, Training, Maintenance
    Application: Lipstick In Pan, Lip Balm, Sheabutter, Lotion, Shampoo,etc Modular Design: Filling Machine, Conveyor, Reheating Machine And Collection Table
    High Light:

    Balm Stick Cosmetic Filling Machine

    ,

    50ml Lip Balm Filling Equipment

    ,

    GMP 4 Nozzles Cosmetic Filling Machine

    Lip Balm Filling Equipment Balm Stick Cosmetic Filling Machine (JYF-4) is our latest design, it is used for either hot filling or cold filling cosmetic products.


    Applications of Lip Balm Filling Equipment Balm Stick Cosmetic Filling Machine

    • hot filling for viscosity products, like lipstick in pan, lip balm, sheabutters, foundation, etc;
    • cold filling for great fluids, such as lotion, shampoo, and other oily products.


    Key Features of Lip Balm Filling Equipment Balm Stick Cosmetic Filling Machine

    This filling line consists of 4 parts, filling machine, conveyor, re-heating machine, and collection table. The output is 15 - 45 pcs per minute according to different filling volumes.

    1. Filling Machine
    Filling Nozzle 4 nozzles, bottom filling, and top filling, nozzle distance adjustable
    Filling Tank Volume 50L
    Filling Tank Material 3 layers tank with heating/stirring/vacuum sucking functions, outer layer: SUS304, inner layer: sus316L, comply with GMP standard
    Filling Tank Temperature Control material temperature detection, oil temperature detection, filling nozzle temperature detection
    Filling Type suitable for both cold and hot filling, filling volume up to 100ml
    Filling Valve new design, FAST DISASSEMBLING TYPE, you can select different filling valve to fulfill your different filling volume, with fast changeover
    Filling Tube new design adopts heating coiled tube instead of oil heating one, more safety and sanitary



    2. Conveyor
    conveyor belt adopts Teflon PVC, which has good performance on resisting high temperature
    conveyor connection with patent design, with motivation transfer/ live roller bridge type
    Motor JSCC speed motor, conveyor speed adjustable



    3. Reheating Machine
    a. adopts quartz heating lamps with cover as our surface re-heating system
    b. the re-heating system can be lifted up and down, which driven by a cylinder



    4. Collection Table


    Main Elements of Lip Balm Filling Equipment Balm Stick Cosmetic Filling Machine

    • Mitsubishi Electric PLC control system with HMI touch screen;
    • JSCC speed motor to adjust conveyor speed



    3 Layers 50ml Lip Balm Stick Cosmetic Filling Machine With 4 Nozzles 03 Layers 50ml Lip Balm Stick Cosmetic Filling Machine With 4 Nozzles 13 Layers 50ml Lip Balm Stick Cosmetic Filling Machine With 4 Nozzles 23 Layers 50ml Lip Balm Stick Cosmetic Filling Machine With 4 Nozzles 33 Layers 50ml Lip Balm Stick Cosmetic Filling Machine With 4 Nozzles 4



    3 Layers 50ml Lip Balm Stick Cosmetic Filling Machine With 4 Nozzles 53 Layers 50ml Lip Balm Stick Cosmetic Filling Machine With 4 Nozzles 63 Layers 50ml Lip Balm Stick Cosmetic Filling Machine With 4 Nozzles 7
