| Brand Name: | GIENICOS |
Production capacity at 3600-5400pcs/hour (label length at 50-150MM)
Adopts SUS304 and engineering plastic meets GMP and FDA standard.
l Brief introduction
These series packagers adopt hot air circulating shrinkage, mainly for shrinking such containers as bottles, jars and cups etc. It can shrink label on the body as well as the cap of bottles. It can be used for foodstuff, beverage, pharmacy, cosmetics and pesticide industries.
l Charateristics
Servo driven Synchronous Belt
The servo is used as the synchronous belt to convey the power, so that the output power is more intelligent, and the linkage matching with the sleeve servo motor and the automatic origin reset function are realized, and the mold and synchronous belt are designed with imported mold opening blocks, so as to ensure the dimensional unity between each mold and the sleeve.
Configuration
|
Item |
Name |
Brand |
|
1 |
Servo Motor |
Mitsubishi |
|
2 |
Reducer |
REDUCER |
|
3 |
Bearing |
SKF |
|
4 |
Belt |
SHUOTIAN |
|
5 |
Mold |
GIENICOS |
|
6 |
Sensor Switch |
Keyence |
Servo Tracking Type Label Sleeve System
The mechanism includes 3 sets of servo drive systems, and the first set of standard delivery power adopts servo obedience to ensure the fixed length accuracy of the standard delivery. The second set of rotary cutters adopts servo drive, which can realize high-speed precise start-stop and overload protection functions. The third set is the tracking function that matches the same speed with the mold timing belt.
Configuration
|
Item |
Name |
Brand |
|
1 |
Servo Motor |
Mitsubishi |
|
2 |
Rotary Knife |
GIENICOS |
|
3 |
Bearing |
SKF |
|
4 |
Belt |
SHUOTIAN |
|
5 |
Guide Rail |
HIWIN |
|
6 |
Sensor Switch |
Keyence |
Servo Clamping Type Chain Conveyor
The servo Clamping type Chain conveyor‘s power adopts servo, which is mainly to realize triple synchronization with the sleeve mechanism and the mold synchronous belt, and the equipment automatically finds the origin. So that commissioning is no longer limited to mechanical fit.
Configuration
|
Item |
Name |
Brand |
|
1 |
Servo Motor |
Mitsubishi |
|
2 |
Chain |
Donghua |
|
3 |
Bearing |
SKF |
|
4 |
CEM tracker |
Mitsubishi |
|
5 |
Linear Bearing |
Igus |
|
6 |
Clamping Slide |
GIENICOS |
Individual Temp. Controller Shrink Tunnel
The shrinking furnace is made of imported 304 stainless steel welding, and the temperature of each area can be adjusted separately, so as to adapt to the shrinkage of various labels such as transparent, copywriting, and barcodes
|
Item |
Name |
Brand |
|
1 |
Guide Air Cylinder |
FESTO |
|
2 |
Rotate Air Cylinder |
FESTO |
|
3 |
Heat Release Fan |
Shanghai |
|
4 |
Ceramic heating Plate |
GIENICOS |
|
6 |
Clamping Slide |
GIENICOS |
Label Feeding System
The feeding mechanism is assembled and manufactured with high-strength aluminum alloy, and the horizontal and longitudinal label winding design is adopted, which can adapt to a variety of labels and realize the sharing of positive and negative wearing labels. The random material rack is made of imported 304 stainless steel
|
Item |
Name |
Brand |
|
1 |
Bearing |
Skf |
|
2 |
Motor |
JSCC |
|
3 |
Sensor Switch |
SICK |
|
4 |
Aluminum Alloy Press wheel |
GIENICOS |
|
5 |
Rubber Wheel |
GIENICOS |
|
6 |
Label Plate |
GIENICOS |
l Label product photo
l Specification
|
Model |
JSS-01 |
||
|
Speed/Direction (Left to right) |
L长度 |
Min最短50mm |
Max最长150mm |
|
Dia.截面/直径 |
Dia.直径8~25mm |
Dia.直径8~25mm |
|
|
Speed速度 |
60-100pcs/min |
50-80 pcs/min |
|
|
Label Material |
PVC/PET/OPS |
||
|
Label Thickness |
0.04mm~0.13mm |
||
|
Labeling Precision |
Label perimeter size≤Product circumference size 4mm |
||
|
Qualify rate |
99% |
||
|
Label Cut Precision |
±0.1mm |
||
|
Dimension |
2040mm(L)× 1300mm(W)× 1400mm(H) |
||
|
Weight |
SUS304不锈钢+6061aluminum Alloy铝合金, 1600KG(About) |
||
|
Power Supply |
3 Phase / 380V 50/60 HZ |
||
|
Power |
10KW |
||
